| Quantity: | |
|---|---|
PTU-800
PROBEST
90268090
China Probest Instrument for Measuring Turbidity Turbidimeter Sesor Measure in Water Price
u The sensor adopts dual-beam infrared scattered light
photometer detection technology and has good repeatability and stability.
u Use ISO7027 Standard Method (Infrared light scattering technique) to eliminate effects of sample color.
u Built-in self-diagnosis function to ensure the accuracy of data.
u Optional cleaning brush of automatic cleaning function to reduce the maintenance of sensor.
u Digital sensor,high anti-jamming capacity and far transmission distance.
n Applications
u Turbidity online monitoring of water inlet, settling basin of water plant.
u Turbidity online monitoring of sewage plant, industrial process water and waste water treatment.
n Technical Specifications
in Line Water Turbidity Meter Turbidity Testing Equipment Manufacturers
Measurement range | Turbidity：0.01-100 NTU，0.01－4000 NTU |
Measurement accuracy | Less than±2% of the measured reading or ±0.1NTU,whichever is greater |
Pressure range | ≤0.4Mpa |
Flow rate | ≤2.5m/s、8.2ft/s |
Calibration | Sample calibration,Slope calibration |
Main material | Body：SUS316L（fresh water），Titanium alloy (marine)； Cover：POM；Cable：PUR |
Power supply | AC：85-500VAC (50/60HZ) DC：9~36VDC |
Output | 3-way 4-20mA |
Relay | Three-way relays, programmed response parameter and response value. |
Communication protocol | MODBUS RS485 |
Storage temperature | -15-50℃ |
Measuring temperature | 0-45℃（Non-freezing） |
Dimension | Sensor：Dia 60mm*L 256mm Transmitter：145*125*162mm(L*W*H) |
Weight | Sensor：1.65KG；Transmitter：1.35KG |
Protective rate | Sensor：IP68/NEMA6P；Transmitter：IP65/ NEMA4X |
Cable length | Standard:10m,the maximum may be extended to 100m |
Features:
1. The sensor adopts dual-beam infrared scattered light photometer detection technology and has good repeatability and stability.
2. Use ISO7027 Standard Method (Infrared light scattering technique) to eliminate effects of sample color.
3. Built-in self-diagnosis function to ensure the accuracy of data.
Optional cleaning brush of automatic cleaning function to reduce the maintenance of sensor.
4. Digital sensor,high anti-jamming capacity and far transmission distance.
5. Standard digital signal output,can achieve integration and networking with other equipment without controller.
6. Plug-and-play sensors,quick and easy installation.
Applications:
1. Turbidity online monitoring of water inlet, settling basin of water plant.
2. Turbidity online monitoring of sewage plant,industrial process water and waste water treatment.
WHY CHOOSE US:
Probest is a professional ISO9001 certificated manufacturer with many patents specializing in researching, developing, producing of water analysis instruments, including portable water analyzer, multi-parameter water quality analyzer, data acquisition and transmission terminal. The product can be applied to the fields of water quality monitoring of drinking water, waste water, surface water, aquaculture water, industrial process water, etc.
Probest is a reliable company including 30+ researcher, focusing on the development of sensor technology to make water analysis faster, simpler, greener and better.
Quality is our core advantages, providing stable and reliable water quality analysis.
China Probest Instrument for Measuring Turbidity Turbidimeter Sesor Measure in Water Price
u The sensor adopts dual-beam infrared scattered light
photometer detection technology and has good repeatability and stability.
u Use ISO7027 Standard Method (Infrared light scattering technique) to eliminate effects of sample color.
u Built-in self-diagnosis function to ensure the accuracy of data.
u Optional cleaning brush of automatic cleaning function to reduce the maintenance of sensor.
u Digital sensor,high anti-jamming capacity and far transmission distance.
n Applications
u Turbidity online monitoring of water inlet, settling basin of water plant.
u Turbidity online monitoring of sewage plant, industrial process water and waste water treatment.
n Technical Specifications
in Line Water Turbidity Meter Turbidity Testing Equipment Manufacturers
Measurement range | Turbidity：0.01-100 NTU，0.01－4000 NTU |
Measurement accuracy | Less than±2% of the measured reading or ±0.1NTU,whichever is greater |
Pressure range | ≤0.4Mpa |
Flow rate | ≤2.5m/s、8.2ft/s |
Calibration | Sample calibration,Slope calibration |
Main material | Body：SUS316L（fresh water），Titanium alloy (marine)； Cover：POM；Cable：PUR |
Power supply | AC：85-500VAC (50/60HZ) DC：9~36VDC |
Output | 3-way 4-20mA |
Relay | Three-way relays, programmed response parameter and response value. |
Communication protocol | MODBUS RS485 |
Storage temperature | -15-50℃ |
Measuring temperature | 0-45℃（Non-freezing） |
Dimension | Sensor：Dia 60mm*L 256mm Transmitter：145*125*162mm(L*W*H) |
Weight | Sensor：1.65KG；Transmitter：1.35KG |
Protective rate | Sensor：IP68/NEMA6P；Transmitter：IP65/ NEMA4X |
Cable length | Standard:10m,the maximum may be extended to 100m |
Features:
1. The sensor adopts dual-beam infrared scattered light photometer detection technology and has good repeatability and stability.
2. Use ISO7027 Standard Method (Infrared light scattering technique) to eliminate effects of sample color.
3. Built-in self-diagnosis function to ensure the accuracy of data.
Optional cleaning brush of automatic cleaning function to reduce the maintenance of sensor.
4. Digital sensor,high anti-jamming capacity and far transmission distance.
5. Standard digital signal output,can achieve integration and networking with other equipment without controller.
6. Plug-and-play sensors,quick and easy installation.
Applications:
1. Turbidity online monitoring of water inlet, settling basin of water plant.
2. Turbidity online monitoring of sewage plant,industrial process water and waste water treatment.
WHY CHOOSE US:
Probest is a professional ISO9001 certificated manufacturer with many patents specializing in researching, developing, producing of water analysis instruments, including portable water analyzer, multi-parameter water quality analyzer, data acquisition and transmission terminal. The product can be applied to the fields of water quality monitoring of drinking water, waste water, surface water, aquaculture water, industrial process water, etc.
Probest is a reliable company including 30+ researcher, focusing on the development of sensor technology to make water analysis faster, simpler, greener and better.
Quality is our core advantages, providing stable and reliable water quality analysis.
