China Probest Hot-selling Online RS485 Digital Turbidimeter Self-cleaning Turbidity Meter Water Turbidity Sensor

100% test with reliable quality China Probest Probest Hot-selling Online Digital Turbidimeter Self-cleaning Turbidity Meter Water Turbidity Sensor with RS485
Availability:
Quantity:
  • PTU-800

  • PROBEST

  • 90268090

PTU800 China Probest Hot-selling RS485Online Digital Turbidimeter Self-cleaning Turbidity Meter Water Turbidity Sensor


u  The sensor adopts dual-beam infrared scattered light

photometer detection technology and has good repeatability and stability.

u  Use ISO7027 Standard Method (Infrared light scattering technique) to eliminate effects of sample color.

u  Built-in self-diagnosis function to ensure the accuracy of data.

u  Optional cleaning brush of automatic cleaning function to reduce the maintenance of sensor.

u  Digital sensor,high anti-jamming capacity and far transmission distance.


n  Applications

u  Turbidity online monitoring of water inlet, settling basin of water plant.

u  Turbidity online monitoring of sewage plant, industrial process water and waste water treatment.


n  Technical Specifications


PTU800 Probest China RS485 Online Measure Turbidity Meters And Sensors Measurement And Monitoring in Water Quality Analysis


Measurement range

Turbidity0.01-100 NTU0.014000 NTU

Measurement   accuracy

Less  than±2%  of    the  measured  reading     or ±0.1NTU,whichever is   greater

Pressure range

≤0.4Mpa

Flow   rate

≤2.5m/s8.2ft/s

Calibration

Sample calibration,Slope calibration

Main   material

Body:SUS316L(fresh   water),Titanium alloy (marine)

CoverPOMCablePUR

Power supply

AC:85-500VAC (50/60HZ)    DC:9~36VDC

Output

3-way 4-20mA

Relay

Three-way relays, programmed response parameter

and response value.

Communication   protocol

MODBUS RS485

Storage temperature

-15-50℃

Measuring   temperature

0-45℃(Non-freezing)

Dimension

SensorDia 60mm*L 256mm

Transmitter145*125*162mm(L*W*H)

Weight

Sensor1.65KGTransmitter1.35KG

Protective rate

SensorIP68/NEMA6PTransmitterIP65/ NEMA4X

Cable   length

Standard:10m,the   maximum may be extended to 100m


Features:
1. The sensor adopts dual-beam infrared scattered light photometer detection technology and has good repeatability and stability.
2. Use ISO7027 Standard Method (Infrared light scattering technique) to eliminate effects of sample color.
3. Built-in self-diagnosis function to ensure the accuracy of data.
Optional cleaning brush of automatic cleaning function to reduce the maintenance of sensor.
4. Digital sensor,high anti-jamming capacity and far transmission distance.
5. Standard digital signal output,can achieve integration and networking with other equipment without controller.
6. Plug-and-play sensors,quick and easy installation.

Applications:
1. Turbidity online monitoring of water inlet, settling basin of water plant.
2. Turbidity online monitoring of sewage plant,industrial process water and waste water treatment.



WHY CHOOSE US:

Probest is a professional ISO9001 certificated manufacturer with many patents specializing in researching, developing, producing of water analysis instruments, including portable water analyzer, multi-parameter water quality analyzer, data acquisition and transmission terminal. The product can be applied to the fields of water quality monitoring of drinking water, waste water, surface water, aquaculture water, industrial process water, etc.
Probest is a reliable company including 30+ researcher, focusing on the development of sensor technology to make water analysis faster, simpler, greener and better.
Quality is our core advantages, providing stable and reliable water quality analysis.

 PTU800 Probest China Online Turbidity Sensor Probe

PRODUCT SHOW

PTU800 Probest China Online Turbidity Sensor Probe

ABOUT US

PTU800 Probest China Online Turbidity Sensor ProbePTU800 Probest China Online Turbidity Sensor Probe

EXHIBITION

PTU800 Probest China Online Turbidity Sensor Probe

Porbest Factory Review First Source Direct Factory

PRODUCTION PROCESS Probest professional and stric quality control water probe(1)
CERTIFICATE

ISO certificated water analysis factory

PACKAGE & SHIPMENT

PTU800 Probest China Online Turbidity Sensor Probe

Probest on exibition(1)

FAQ

PTU800 Probest China Online Turbidity Sensor Probe
