PMI800-ORP
PROBEST
Principle of Measurement
Portable ORP analyzer consists of portable host and portable ORP sensor. The sensor uses composite electrode composed of a glass indicator electrode and a reference electrode to measure ORP value of water quality, data stability and reliable performance.
Features
l The host with IP67 protection rating;
l 3.5-inch color screen display, interface menu design is beautiful, easy to operate;
l Ergonomic curve design, suitable for hand grip, with rubber non-slip hand strap, not easy to slip in wet environment;
l With data storage function, and data export through USB interface;
l Built-in rechargeable battery and charging directly via USB without disassembling the battery;
l Automatically identify the connected sensor type and the reading interface automatically adapts;
l The sensor can be parameterized and calibrated;
Typical Application
l It is widely used in on-site portable monitoring of ORP in aquaculture, sewage treatment, surface water, industrial and agricultural water supply and drainage, domestic water, swimming pools, scientific research universities and other industries and fields.
Sensor Specifications
Measurement range | -2000mV ~ +2000mV |
Resolution | 1mV |
Accuracy | ±2mV（electronic component） |
Display | 3.5-inch color display screen with adjustable backlight |
Power supply | Built-in battery power, battery specifications: 4 3.7V rechargeable lithium battery |
Data storage | More than 100,000 data |
Material | Mainframe:ABS+PC |
Protection level | Mainframe: IP67,sensor: IP68/NEMA6P |
Operating temp. | 0~50℃（Non-freezing） |
Storage temperature | -15~60℃ |
Size&Weight | Mainframe:203*100*43mm,0.5KG |
Cable length | Standard: 3 m(The cable can be extendable) |
