PUVCOD-600
PROBEST
The whole detection process requires no chemical reagents, achieving pollution-free and long-term continuous monitoring.
Adopt 254nm UV spectral detection technology, realize multi-parameter simultaneous measurement of COD, TOC, BOD and turbidity
Direct immersion probe design, no need for sampling and water sample pretreatment
Reagent-free detection, no secondary environmental pollution, low operation cost
High-efficiency LED light source, compact structure, low power consumption, easy on-site integration and installation
Built-in automatic cleaning device, effectively reduce dirt accumulation and manual maintenance
Equipped with power positive and negative reverse protection and RS485 terminal protection, strong anti-interference ability
Support real-time time display, data storage and historical data query
Flexible configuration, optional wireless data transmission module for remote monitoring-
Online monitoring of organic pollutants in sewage treatment plants, real-time detection of inlet and outlet water quality
Continuous monitoring of industrial wastewater production and discharge water quality
Surface water, river water, lake water and environmental water quality monitoring
Fishery water, circulating water and other water body organic component detection
| Item | Specification |
|---|---|
| Model | PUVCOD-600 UV Spectrometer Online Analyzer |
| Detection Range | COD (KHP calibration): 0~1000mg/L BOD (KHP calibration): 0~750mg/L TOC (KHP calibration): 0~400mg/L Turbidity: 10~1000 NTU |
| Accuracy | COD / BOD / TOC: ±5% (KHP calibration)Turbidity: ±10% |
| Measurement Interval | Minimum 1 minute |
| Pressure Resistance | ≤0.1Mpa |
| Sensor Material | SUS316L stainless steel |
| Power Supply | AC: 85~500VAC (50/60HZ) DC: 9~36VDC |
| Output Interface | 3-channel 4-20mA analog output |
| Relay | 3-channel configurable relay, support parameter linkage setting |
| Communication Protocol | MODBUS RS485 |
| Storage Temperature | -15℃ ~ 50℃ |
| Working Temperature | 0℃ ~ 45℃ |
| Sensor Size | Diameter 34mm × Length 217mm |
| Weight | 0.8KG |
| Protection Grade | IP68 / NEMA6P |
| Cable Length | Standard 10m, maximum extendable to 100m |
| Spare Parts | Optional UVCOD sensor cleaning scraper |
PUVCOD-600 Spectrometer UVCOD/UV254/BODuv/TOCuv bod cod testing equipment UVCOD Sensor
     |
